STK Series Fiber Coupled Laser Diodes (500W) Our STK series fiber-coupled laser diodes can be pided into two categories: single emitter laser diodes and multi-single emitter laser diodes. 1. Single Emitter Laser Diodes Single emitter laser diodes can
Features:
405nm~1650nm
SM and PM Fiber
1mW~100mW Output Power
PER upto 20dB
Built-in TE Cooler Optional
Built-in Photodiode Optional
Long Lifetime
High Stability
Customized Wavelength
Customized Output Power
We offer High Coupling Efficient Solution for 405nm~1650nm Pigtailed Laser Module with Single Mode Fiber and Polarization Maintaining Fiber and the output power can be up to 100mW. We adopt unique technique to get high Polarization Extinction Ratio (PER), which is up to 20dB with Low Noise Laser Output.
With SM and PM Fiber, it can get the Gauss Beam which is the Single Transverse Mode Beam, the M2 value is less 1.3. Meanwhile, and the TE Cooler and Photodiode is optional for customers. We can integrate them into the Laser Module according to customer's requirement. We also offer the Customized Solution for Pigtailed Laser Modules, such as Customized Wavelength and Customized Power to meet the special needs of customers.
We use laser welding technology to guarantee the long-term reliability of the laser structure. To ensure the long-term reliability, each laser diode will undergo rigorous testing and aging in factory. Meanwhile the high-low storage temperature circulation is also necessary for each laser diode. We set the storage temperature range from -40 degree C to +85 degree C, and it lasts 10 cycles. In this way, it ensures the long-term reliability of the coupling structure.
Part Number | Wavelength | Output Power | Package | Other Specification |
STW-WSLP-405-002m-10-PD | 405nm | 2mW | Coaxial | UV 10um Fiber |
STW-WSLP-405-005m-4 | 405nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-002m-4-PD | 405nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-015m-4 | 405nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-015m-PM | 405nm | 15mW | Coaxial | PM Fiber |
STW-WSLP-405-030m-4 | 405nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-030m-PM | 405nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-405-050m-4 | 405nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-050m-10 | 405nm | 50mW | Coaxial | UV 10um Fiber |
STW-WSLP-405-050m-PM | 405nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-405-080m-4 | 405nm | 80mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-080m-PM | 405nm | 80mW | Coaxial | PM Fiber |
STW-WSLP-405-100m-4 | 405nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-405-100m-10 | 405nm | 100mW | Coaxial | UV 10um Fiber |
STW-WSLP-405-100m-PM | 405nm | 100mW | Coaxial | PM Fiber |
STW-WSLX-405-015m-4-T | 405nm | 15mw | 14-Pin | Single Mode Fiber |
STW-WSLP-445-015m-4 | 445nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-445-015m-PM | 445nm | 15mW | Coaxial | PM Fiber |
STW-WSLX-445-015m-4-T | 445nm | 15mw | 14-Pin | Single Mode Fiber |
STW-WSLP-445-020m-4 | 445nm | 20mw | Coaxial | Single Mode Fiber |
STW-WSLX-445-020m-4-T | 445nm | 20mw | 14-Pin | Single Mode Fiber |
STW-WSLP-445-030m-4 | 445nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-445-030m-PM | 445nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-445-040m-4 | 445nm | 40mW | Coaxial | Single Mode Fiber |
STW-WSLP-445-040m-PM | 445nm | 40mW | Coaxial | PM Fiber |
STW-WSLP-445-050m-4 | 445nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-445-050m-PM | 445nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-445-050m-10 | 445nm | 50mW | Coaxial | UV 10um Fiber |
STW-WSLP-488-010m-4 | 488nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-488-010m-PM | 488nm | 10mW | Coaxial | PM Fiber |
STW-WSLP-488-015m-PM | 488nm | 15mW | Coaxial | PM Fiber |
STW-WSLP-488-015m-4 | 488nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-488-020m-4 | 488nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-488-020m-9 | 488nm | 20mW | Coaxial | 9um Fiber |
STW-WSLP-488-020m-PM | 488nm | 20mW | Coaxial | PM Fiber |
STW-WSLP-488-030m-4-PD | 488nm | 30mW | Coaxial | Single mode fiber |
STW-WSLP-488-030m-PM-PD | 488nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-505-005m-4-PD | 505nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-505-005m-PM-PD | 505nm | 5mW | Coaxial | PM Fiber |
STW-WSLP-505-010m-4 | 505nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-505-010m-PM | 505nm | 10mW | Coaxial | PM Fiber |
STW-WSLP-505-020m-4 | 505nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-505-020m-9 | 505nm | 20mW | Coaxial | 9um Fiber |
STW-WSLP-505-020m-PM | 505nm | 20mW | Coaxial | PM Fiber |
STW-WSLP-520-001m-4-PD | 520nm | 1mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-010m-4 | 520nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-005m-4 | 520nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-010m-4-PD | 520nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-010m-9-PD | 520nm | 10mW | Coaxial | 9um Fiber |
STW-WSLP-520-010m-PM-PD | 520nm | 10mW | Coaxial | PM Fiber |
STW-WSLX-520-010m-4-T-PD | 520nm | 10mW | 14-Pin | Single Mode Fiber |
STW-WSLX-520-010m-PM-T-PD | 520nm | 10mW | 14-Pin | PM Fiber |
STW-WSLP-520-015m-4-PD | 520nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-015m-PM-PD | 520nm | 15mW | Coaxial | PM Fiber |
STW-WSLP-520-020m-4 | 520nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-020m-4-PD | 520nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-020m-9-PD | 520nm | 20mW | Coaxial | 9um Fiber |
STW-WSLP-520-020m-PM-PD | 520nm | 20mW | Coaxial | PM Fiber |
STW-WSLP-520-025m-4-PD | 520nm | 25mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-025m-PM-PD | 520nm | 25mW | Coaxial | PM Fiber |
STW-WSLP-520-030m-4 | 520nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-030m-4-PD | 520nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-030m-9-PD | 520nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-520-030m-PM | 520nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-633-030m-4-PD | 633nm | 30mw | Coaxial | Single Mode Fiber |
STW-WSLP-633-030m-PM-PD | 633nm | 30mw | Coaxial | PM Fiber |
STW-WSLP-633-060m-4 | 633nm | 60mw | Coaxial | Single Mode Fiber |
STW-WSLP-633-060m-PM | 633nm | 60mw | Coaxial | PM Fiber |
STW-WSLP-635-001m-4-PD | 635nm | 1mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-002m-4-PD | 635nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-003m-4-PD | 635nm | 3mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-005m-4-PD | 635nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-005m-9-PD | 635nm | 5mw | Coaxial | 9um Fiber |
STW-WSLP-635-010m-4-PD | 635nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-010m-PM-PD | 635nm | 10mW | Coaxial | PM Fiber |
STW-WSLP-635-015m-4-PD | 635nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-020m-4 | 635nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-020m-4-PD | 635nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-020m-PM | 635nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLX-635-020m-4-T | 635nm | 20mw | 14-Pin | Single Mode Fiber |
STW-WSLP-635-030m-4 | 635nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-050m-4-PD | 635nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-635-050m-9-B-R | 635nm | 50mW | B82 | 9um Fiber |
STW-WSLP-635-050m-PM | 635nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-635-050m-PM-PD | 635nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-635-060m-4 | 635nm | 60mw | Coaxial | Single Mode Fiber |
STW-WSLP-635-060m-PM | 635nm | 60mw | Coaxial | PM Fiber |
STW-WSLP-635-070m-4 | 635nm | 70mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-003m-4-PD | 650nm | 3mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-005m-4-PD | 650nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-010m-4-PD | 650nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-010m-PM-PD | 650nm | 10mW | Coaxial | PM Fiber |
STW-WSLP-650-015m-4-PD | 650nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-020m-4 | 650nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-020m-4-PD | 650nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLX-650-020m-4-T | 650nm | 20mw | 14-Pin | Single Mode Fiber |
STW-WSLP-650-020m-9 | 650nm | 20mW | Coaxial | 9um Fiber |
STW-WSLX-650-030m-4-T | 650nm | 30mw | 14-Pin | Single Mode Fiber |
STW-WSLP-650-040m-4 | 650nm | 40mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-040m-9 | 650nm | 40mW | Coaxial | 9um Fiber |
STW-WSLP-650-050m-4 | 650nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-050m-9 | 650nm | 50mW | Coaxial | 9um Fiber |
STW-WSLX-650-050m-4-T | 650nm | 50mw | 14-Pin | Single Mode Fiber |
STW-WSLP-650-050m-PM | 650nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-650-080m-4 | 650nm | 80mW | Coaxial | Single Mode Fiber |
STW-WSLP-650-080m-9 | 650nm | 80mW | Coaxial | 9um Fiber |
STW-WSLP-650-080m-PM | 650nm | 80mW | Coaxial | PM Fiber |
STW-WSLP-650-100m-4 | 650nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-670-002m-4-PD | 670nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-670-003m-4-PD | 670nm | 3mw | Coaxial | Single Mode Fiber |
STW-WSLP-670-003m-PM-PD | 670nm | 3mW | Coaxial | PM Fiber |
STW-WSLX-670-003m-4-T-PD | 670nm | 3mw | 14-Pin | Single Mode Fiber |
STW-WSLP-670-005m-4-PD | 670nm | 5mw | Coaxial | Single Mode Fiber |
STW-WSLP-670-005m-9-PD | 670nm | 5mW | Coaxial | 9um Fiber |
STW-WSLP-670-005m-PM-PD | 670nm | 5mW | Coaxial | PM Fiber |
STW-WSLX-670-005m-4-T-PD | 670nm | 5mw | 14-Pin | Single Mode Fiber |
STW-WSLP-685-010m-4-PD | 685nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-685-010m-PM-PD | 685nm | 10mW | Coaxial | PM Fiber |
STW-WSLX-685-010m-4-T-PD | 685nm | 10mw | 14-Pin | Single Mode Fiber |
STW-WSLP-685-015m-4-PD | 685nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-685-015m-9-PD | 685nm | 15mW | Coaxial | 9um Fiber |
STW-WSLP-685-015m-PM-PD | 685nm | 15mW | Coaxial | PM Fiber |
STW-WSLP-685-020m-4-PD | 685nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-685-030m-PM-PD | 685nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-690-010m-4-PD | 690nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-705-030m-4-PD | 705nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-705-030m-PM-PD | 705nm | 30mW | Caaxial | PM Fiber |
STW-WSLP-730-030m-4-PD | 730nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-730-030m-PM-PD | 730nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-785-005m-4-PD | 785nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-785-010m-9-PD | 785nm | 10mW | Coaxial | 9um Fiber |
STW-WSLX-785-015m-4-T-PD | 785nm | 15mw | 14-Pin | Single Mode Fiber |
STW-WSLP-785-020m-4-PD | 785nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-785-020m-PM-PD | 785nm | 20mW | Coaxial | PM Fiber |
STW-WSLX-785-020m-4-T-PD | 785nm | 20mw | 14-Pin | Single Mode Fiber |
STW-WSLP-785-030m-4-PD | 785nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-785-030m-9-PD | 785nm | 30mW | Coaxial | 9um Fiber |
STW-WSLP-785-030m-PM-PD | 785nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-785-050m-4-PD | 785nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-785-050m-PM-PD | 785nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-785-060m-4-PD | 785nm | 60mw | Coaxial | Single Mode Fiber |
STW-WSLP-785-060m-PM-PD | 785nm | 60mw | Coaxial | PM Fiber |
STW-WSLP-800-030m-4-PD | 800nm | 30mW | Coaxial | Single Mode |
STW-WSLP-800-030m-PM-PD | 800nm | 30mW | Coaxial | PM Fiber |
STW-WSLX-808-005m-4-T-PD | 808nm | 5mw | 14-Pin | Single Mode Fiber |
STW-WSLP-808-015m-PM-PD | 808nm | 15mW | Coaxial | PM Fiber |
STW-WSLP-808-020m-4-PD | 808nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-808-030m-4-PD | 808nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-808-030m-9-PD | 808nm | 30mW | Coaxial | 9um Fiber |
STW-WSLP-808-030m-PM-PD | 808nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-808-040m-4-PD | 808nm | 40mW | Coaxial | Single Mode Fiber |
STW-WSLP-808-040m-PM-PD | 808nm | 40mW | Coaxial | PM Fiber |
STW-WSLP-808-050m-4-PD | 808nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-808-050m-PM-PD | 808nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-808-100m-4-PD | 808nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-808-100m-PM-PD | 808nm | 100mW | Coaxial | PM Fiber |
STW-WSLP-830-005m-4-PD | 830nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-830-010m-9-PD | 830nm | 10mW | Coaxial | 9um Fiber |
STW-WSLP-830-030m-4-PD | 830nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLX-830-030m-4-T-PD | 830nm | 30mw | 14-Pin | Single Mode Fiber |
STW-WSLP-830-030m-PM-PD | 830nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-830-050m-4-PD | 830nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-830-050m-9-PD | 830nm | 50mw | Coaxial | 9um Fiber |
STW-WSLP-830-050m-PM-PD | 830nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-830-080m-4-PD | 830nm | 80mW | Coaxial | Single Mode Fiber |
STW-WSLP-830-080m-PM-PD | 830nm | 80mW | Coaxial | PM Fiber |
STW-WSLP-830-100m-4-PD | 830nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-830-100m-9-PD | 830nm | 100mW | Coaxial | 9um Fiber |
STW-WSLP-830-100m-PM-PD | 830nm | 100mW | Coaxial | PM Fiber |
STW-WSLP-850-001m-4-PD | 850nm | 1mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-002m-9-PD | 850nm | 2mW | Coaxial | 9um Fiber |
STW-WSLP-850-005m-4-PD | 850nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-010m-4-PD | 850nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-010m-9-PD | 850nm | 10mw | Coaxial | 9um Fiber |
STW-WSLP-850-020m-9-PD | 850nm | 20mW | Coaxial | 9um Fiber |
STW-WSLX-850-020m-4-T-PD | 850nm | 20mw | 14-Pin | Single Mode Fiber |
STW-WSLP-850-030m-4-PD | 850nm | 30mw | Coaxial | Single Mode Fiber |
STW-WSLP-850-030m-PM-PD | 850nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-850-050m-4-PD | 850nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-050m-9-PD | 850nm | 50mW | Coaxial | 9um Fiber |
STW-WSLP-850-050m-PM-PD | 850nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-850-070m-4-PD | 850nm | 70mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-070m-PM-PD | 850nm | 70mW | Coaxial | PM Fiber |
STW-WSLP-850-100m-4-PD | 850nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-850-100m-PM-PD | 850nm | 100mW | Coaxial | PM Fiber |
STW-WSLP-880-001m-4-PD | 880nm | 1mW | Coaxial | Single Mode Fiber |
WSLX-880-001m-4-T-PD | 880nm | 1mw | 14-Pin | Single Mode Fiber |
STW-WSLP-880-002m-4-PD | 880nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-880-002m-9-PD | 880nm | 2mW | Coaxial | 9um Fiber |
STW-WSLP-880-002m-PM-PD | 880nm | 2mW | Coaxial | PM Fiber |
STW-WSLX-905-001m-4-T-PD | 905nm | 1mw | 14-Pin | Single Mode Fiber |
STW-WSLP-905-002m-4-PD | 905nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-905-002m-9-PD | 905nm | 2mW | Coaxial | 9um Fiber |
STW-WSLP-905-015m-4-PD | 905nm | 15mW | Coaxial | Single Mode Fiber |
STW-WSLP-905-030m-4-PD | 905nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-905-030m-PM-PD | 905nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-905-050m-4-PD | 905nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-905-050m-9-PD | 905nm | 50mW | Coaxial | 9um Fiber |
STW-WSLP-905-050m-PM-PD | 905nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-905-070m-4-PD | 905nm | 70mW | Coaxial | Single Mode Fiber |
STW-WSLP-905-070m-PM-PD | 905nm | 70mW | Coaxial | PM Fiber |
STW-WSLP-940-030m-4-PD | 940nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-940-030m-PM-PD | 940nm | 30mW | Coaxial | PM Fiber |
STW-WSLP-940-050m-4-PD | 940nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-940-050m-9-PD | 940nm | 50mW | Coaxial | 9um Fiber |
STW-WSLP-940-050m-PM-PD | 940nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-940-080m-4-PD | 940nm | 80mW | Coaxial | Single Mode Fiber |
STW-WSLP-940-080m-PM-PD | 940nm | 80mW | Coaxial | Single Mode Fiber |
STW-WSLP-940-100m-4-PD | 940nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-940-100m-PM-PD | 940nm | 100mW | Coaxial | PM Fiber |
STW-WSLP-980-005m-4-PD | 980nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLX-980-005m-4-T-PD | 980nm | 5mw | 14-Pin | Single Mode Fiber |
STW-WSLP-980-010m-4-PD | 980nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-980-010m-9-PD | 980nm | 10mW | Coaxial | 9um Fiber |
STW-WSLP-980-010m-PM-PD | 980nm | 10mW | Coaxial | PM Fiber |
STW-WSLX-980-010m-4-T-PD | 980nm | 10mw | 14-Pin | Single Mode Fiber |
STW-WSLP-980-015m-9-PD | 980nm | 15mW | Coaxial | 9um Fiber |
STW-WSLP-980-020m-4-PD | 980nm | 20mW | Coaxial | Single Mode Fiber |
STW-WSLP-980-020m-9-PD | 980nm | 20mW | Coaxial | 9um Fiber |
STW-WSLP-980-030m-4-PD | 980nm | 30mW | Coaxial | Single Mode Fiber |
STW-WSLP-980-030m-9-PD | 980nm | 30mW | Coaxial | 9um Fiber |
STW-WSLP-1055-050m-4-PD | 1055nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-1055-050m-PM-PD | 1055nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-1064-005m-4-PD | 1064nm | 5mW | Coaxial | Single mode Fiber |
STW-WSLP-1064-010m-9-PD | 1064nm | 10mW | Coaxial | 9um fiber |
STW-WSLX-1064-005m-4-T-PD | 1064nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLX-1064-010m-4-T-PD | 1064nm | 10mw | Butterfly | Single Mode Fiber |
STW-WSLP-1064-030m-4-PD | 1064nm | 30mW | Coaxial | 30mW |
STW-WSLP-1064-050m-4-PD | 1064nm | 50mW | Coaxial | Single Mode Fiber |
STW-WSLP-1064-050m-PM-PD | 1064nm | 50mW | Coaxial | PM Fiber |
STW-WSLP-1064-100m-4-PD | 1064nm | 100mW | Coaxial | Single Mode Fiber |
STW-WSLP-1064-100m-PM-PD | 1064nm | 100mW | Coaxial | PM Fiber |
STW-WSLP-1270-002m-9-DFB | 1270nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1270-005m-9-T-DFB | 1270nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1290-002m-9-DFB | 1290nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1290-005m-9-T-DFB | 1290nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1310-002m-9-FP | 1310nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-1310-002m-9-DFB | 1310nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-1310-005m-9-DFB | 1310nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-1310-010m-9-DFB | 1310nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLP-1310-010m-PM-DFB | 1310nm | 10mW | Coaxial | PM Fiber |
STW-WSLX-1310-010m-9-T-DFB | 1310nm | 10mw | Butterfly | Single Mode Fiber |
STW-WSLP-1330-002m-9-DFB | 1330nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1330-005m-9-T-DFB | 1330nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1350-002m-9-DFB | 1350nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1350-005m-9-T-DFB | 1350nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1370-002m-9-DFB | 1370nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1370-005m-9-T-DFB | 1370nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1390-002m-9-DFB | 1390nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1390-005m-9-T-DFB | 1390nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1410-002m-9-DFB | 1410nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1410-005m-9-T-DFB | 1410nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1430-002m-9-DFB | 1430nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1430-005m-9-T-DFB | 1430nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1450-002m-9-DFB | 1450nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1450-005m-9-T-DFB | 1450nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1470-002m-9-DFB | 1470nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1470-005m-9-T-DFB | 1470nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1490-002m-9-DFB | 1490nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1490-005m-9-T-DFB | 1490nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1510-002m-9-DFB | 1510nm | 2mW | Coaxial | Single Mode Fiber |
WSLX-1510-005m-9-T-DFB | 1510nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1530-002m-9-DFB | 1530nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1530-005m-9-T-DFB | 1530nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1550-002m-9-FP | 1550nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-1550-002m-9-DFB | 1550nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLP-1550-005m-9-DFB | 1550nm | 5mW | Coaxial | Single Mode Fiber |
STW-WSLP-1550-008m-9-DFB | 1550nm | 8mW | Coaxial | Single Mode Fiber |
STW-WSLP-1550-008m-PM-DFB | 1550nm | 8mW | Coaxial | PM Fiber |
STW-WSLP-1550-010m-9-DFB | 1550nm | 10mW | Coaxial | Single Mode Fiber |
STW-WSLX-1550-010m-9-T-DFB | 1550nm | 10mw | Butterfly | Single Mode Fiber |
STW-WSLP-1570-002m-9-DFB | 1570nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1570-005m-9-T-DFB | 1570nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1590-002m-9-DFB | 1590nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1590-005m-9-T-DFB | 1590nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1610-002m-9-DFB | 1610nm | 2mW | Coaxial | Single Mode Fiber |
STW-WSLX-1610-005m-9-T-DFB | 1610nm | 5mw | Butterfly | Single Mode Fiber |
STW-WSLP-1625-001m-9-DFB | 1625nm | 1mW | Coaxial | Single Mode Fiber |
Features:
405nm~1920nm
5mW~50W Output Power
50um/ 105um/ 200um/ 400um Fiber Core
Coaxial/ 2-PIN/ 4-PIN/ 14-PIN/ 9-PIN Package
Built-in TE Cooler Optional
Built-in Photodiode Optional
Red/Green Aiming Beam Optional for IR LASER
Long Lifetime
High Stability
Customized Wavelength
Customized Output Power
Customized Fiber Core
We offer High Coupling Efficient Solution for 405nm~1920nm Pigtailed Laser Module with 50um,105um,200um,400um Fiber Core, the output power ranges from 5mW to 50W. Meanwhile, the TE Cooler and Photodiode is optional for customers, the Green or Red Aiming Beam is also optional for IR Lasers. We can integrate these functions into the Laser Module as per customer's requirement. The standard package of the lasers can be Coaxial,2-PIN,4-PIN,14-PIN and 9-PIN.
Part Number | Wavelength | Output Power | Package | Other Specification |
STW-WSLP-405-010m-105M-PD | 405nm | 5~10mW | Coaxial | 105um UV Fiber |
STW-WSLP-405-060m-105M | 405nm | 50~60mW | Coaxial | 105um UV Fiber |
STW-WSLP-405-120m-50M | 405nm | 100~120mW | Coaxial | 50um UV Fiber |
STW-WSLP-405-150m-50M | 405nm | 150mW | Coaxial | 50um UV Fiber |
STW-WSLP-405-150m-105M | 405nm | 150mW | Coaxial | 105um UV Fiber |
STW-WSLP-405-200m-34M | 405nm | 200mW | Coaxial | 34um UV Fiber |
STW-WSLP-405-200m-50M | 405nm | 200mW | Coaxial | 50um UV Fiber |
STW-WSLP-405-200m-105M | 405nm | 200mW | Coaxial | 105um UV Fiber |
STW-WSLP-405-300m-105M | 405nm | 250~300mW | Coaxial | 105um UV Fiber |
STW-WSLP-405-700m-105M | 405nm | 700mW | Coaxial | 105um UV Fiber |
STW-WSLP-445-050m-M | 445nm | 50mW | Coaxial | Multimode |
STW-WSLP-445-500m-M | 445nm | 500mW | Coaxial | Multimode |
STW-WSLX-445-001-H | 445nm | 1.0W | Coaxial | Multimode |
STW-WSLB-445-003-H | 445nm | 3W | P2 | Multimode |
STW-WSLB-445-005-H | 445nm | 5W | P2 | Multimode |
STW-WSLB-445-010-H | 445nm | 10W | P2 | Multimode |
STW-WSLP-520-030m-M-PD | 520nm | 20~30mW | Coaxial | 62.5um |
STW-WSLP-520-030m-M | 520nm | 20~30mW | Coaxial | 62.5um |
STW-WSLP-520-050m-M | 520nm | 50~60mW | Coaxial | 105um |
STW-WSLP-520-100m-M | 520nm | 80~100mW | Coaxial | 105um |
STW-WSLP-520-500m-M | 520nm | 400~500mW | Coaxial | 62.5um |
STW-WSLP-520-800m-M | 520nm | 700~800mW | Coaxial | 105um |
STW-WSLP-635-005m-M-PD | 635nm | 5mW | Coaxial | Multimode |
STW-WSLP-635-010m-M-PD | 635nm | 10mW | Coaxial | Multimode |
STW-WSLP-635-060m-M | 635nm | 60mW | Coaxial | Multimode |
STW-WSLP-635-100m-M | 635nm | 100mW | Coaxial | Multimode |
STW-WSLP-635-200m-M | 635nm | 200mW | Coaxial | Multimode |
STW-WSLP-635-300m-M | 635nm | 250~300mW | Coaxial | Multimode |
STW-WSLP-635-400m-M | 635nm | 400mW | Coaxial | Multimode |
STW-WSLX-635-350m-H | 635nm | 350mW | 2-Pin/4-Pin | Multimode |
STW-WSLB-635-001-H | 635nm | 1W | P2 | Multimode |
STW-WSLB-635-002-H | 635nm | 2W | P2 | Multimode |
STW-WSLB-635-003-H | 635nm | 3W | P2 | Multimode |
STW-WSLP-650-060m-M | 650nm | 60mW | Coaxial | Multimode |
STW-WSLP-650-120m-M | 650nm | 120mW | Coaxial | Multimode |
STW-WSLX-650-350m-H | 650nm | 350mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-650-700m-H | 650nm | 700mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-650-700m-H-T | 650nm | 700mW | 9-Pin | Multimode |
STW-WSLB-650-001-H | 650nm | 1W | P2 | Multimode |
STW-WSLB-650-002-H | 650nm | 2W | P2 | Multimode |
STW-WSLB-650-005-H | 650nm | 5W | P2 | Multimode |
STW-WSLP-660-120m-M | 660nm | 120mW | Coaxial | Multimode |
STW-WSLX-660-700m-H | 660nm | 700mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-660-700m-H-T | 660nm | 700mW | 9-Pin | Multimode |
STW-WSLB-660-002-H | 660nm | 2W | P2 | Multimode |
STW-WSLB-660-005-H | 660nm | 5W | P2 | Multimode |
STW-WSLP-670-005m-M-PD | 670nm | 5mW | Coaxial | Multimode |
STW-WSLP-685-015m-M-PD | 685nm | 15mW | Coaxial | Multimode |
STW-WSLP-690-015m-M-PD | 690nm | 15mW | Coaxial | Multimode |
STW-WSLX-770-001-H | 770nm | 1.5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-770-001-H-T | 770nm | 1.5W | 14-Pin | Multimode |
STW-WSLB-770-004-H | 770nm | 4W | Coaxial | Multimode |
STW-WSLB-770-010-H | 770nm | 10W | P2 | Multimode |
STW-WSLP-785-005m-M-PD | 785nm | 5mW | Coaxial | Multimode |
STW-WSLP-785-050m-M-PD | 785nm | 50mW | Coaxial | Multimode |
STW-WSLP-785-100m-M | 785nm | 100mW | Coaxial | Multimode |
STW-WSLX-785-700m-H | 785nm | 700mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-785-001-H(60um) | 785nm | 1W | 4-Pin/9-Pin | Multimode |
STW-WSLX-785-001-H | 785nm | 1.5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-785-002-H | 785nm | 2W | 4-Pin/9-Pin | Multimode |
STW-WSLB-785-004-H | 785nm | 4W | P2 | Multimode |
STW-WSLB-785-010-H | 785nm | 10W | P2 | Multimode |
STW-WSLX-792-002-H | 793nm | 2W | 2-Pin/4-Pin | Multimode |
STW-WSLX-792-002-H-T | 793nm | 2W | 9-Pin | Multimode |
STW-WSLP-800-030m-M-PD | 800nm | 30mW | Coaxial | Multimode |
STW-WSLX-808-001-H-T-PD | 808nm | 1W | 14-Pin | Multimode |
STW-WSLP-808-120m-M-PD | 808nm | 120mW | Coaxial | Multimode |
STW-WSLP-808-150m-M-PD | 808nm | 150mW | Coaxial | Multimode |
STW-WSLX-808-003-H | 808nm | 3W | 2-Pin/4-Pin | Multimode |
STW-WSLX-808-003-H-T-PD | 808nm | 3W | 9-Pin | Multimode |
STW-WSLX-808-004-H(62.5) | 808nm | 4W | 2-Pin/4-Pin | Multimode |
STW-WSLX-808-005-H | 808nm | 5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-808-005-H-T | 808nm | 5W | 9-Pin | Multimode |
STW-WSLX-808-007-H | 808nm | 7W | 2-Pin | Multimode |
STW-WSLX-808-007-H-T-PD | 808nm | 7W | 9-Pin | Multimode |
STW-WSLX-808-008-H | 808nm | 8W | 2-Pin | Multimode |
STW-WSLX-808-008-H-T | 808nm | 8W | 9-Pin | Multimode |
STW-WSLB-808-012-H | 808nm | 12W | P2 | Multimode |
STW-WSLB-808-014-H | 808nm | 14W | P2 | Multimode |
STW-WSLB-808-020-H | 808nm | 20W | P2 | Multimode |
STW-WSLB-808-028-H | 808nm | 28W | P2 | Multimode |
STW-WSLX-808-012-H | 808nm | 12W | 2-Pin | Multimode |
STW-WSLX-808-020-H | 808nm | 20W | 2-Pin | Multimode |
STW-WSLP-830-015m-M-PD | 830nm | 15mW | Coaxial | Multimode |
STW-WSLP-830-050m-M-PD | 830nm | 50mW | Coaxial | Multimode |
STW-WSLX-830-001-H | 830nm | 1W | 2-Pin/4-Pin | Multimode |
STW-WSLX-830-001-H-T | 830nm | 1W | 14-Pin | Multimode |
STW-WSLX-830-1500m-H | 830nm | 1.5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-830-002-H | 830nm | 2W | 2-Pin/4-Pin | Multimode |
STW-WSLB-830-006-H | 830nm | 6W | P2 | Multimode |
STW-WSLB-830-012-H | 830nm | 12W | P2 | Multimode |
STW-WSLB-830-015-H | 830nm | 15W | P2 | Multimode |
STW-WSLP-830-120m-M-PD | 830nm | 120mw | Coaxial | Multimode |
STW-WSLP-850-005m-M-PD | 850nm | 5mW | Coaxial | Multi-mode |
STW-WSLP-850-030m-M-PD | 850nm | 20~30mW | Coaxial | Multi-mode |
STW-WSLP-850-050m-M-PD | 850nm | 50mW | Coaxial | Multi-mode |
STW-WSLP-850-120m-M-PD | 850nm | 120mW | Coaxial | Multi-mode |
STW-WSLP-850-200m-M-PD | 850nm | 200mW | Coaxial | Multi-mode |
STW-WSLX-850-001-H | 850nm | 1.5W | 4-Pin | Multi-mode |
STW-WSLX-850-001-H-T | 850nm | 1.5W | 9-Pin | Multi-mode |
STW-WSLB-850-003-H | 850nm | 3W | HHL | Multi-mode |
STW-WSLB-850-005-H | 850nm | 5W | HHL | Multi-mode |
STW-WSLP-880-005m-M-PD | 880nm | 5mW | Coaxial | Multimode |
STW-WSLX-880-002-H | 880nm | 2W | 4-Pin | Multimode |
STW-WSLX-880-002-H-T | 880nm | 2W | 9-Pin | Multimode |
STW-WSLX-880-003-H | 880nm | 3W | 2-Pin/4-Pin | Multimode |
STW-WSLB-880-012-H | 880nm | 12W | P2 | Multimode |
STW-WSLB-880-015-H | 880nm | 15W | P2 | Multimode |
STW-WSLX-880-001-H-T-PD | 880nm | 1W | 14-Pin | Multimode |
STW-WSLP-905-005m-M-PD | 905nm | 5mW | Coaxial | Multimode |
STW-WSLP-905-050m-M-PD | 905nm | 50mW | Coaxial | Multimode |
STW-WSLX-915-005-H | 915nm | 5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-915-008-H | 915nm | 8W | 2-Pin/4-Pin | Multimode |
STW-WSLB-915-015-H | 915nm | 15W | P2 | Multimode |
STW-WSLX-940-001-H-T | 940nm | 1.5W | 14-Pin | Multimode |
STW-WSLX-940-003-H | 940nm | 3W | 2-Pin/4-Pi | Multimode |
STW-WSLX-940-004-H-T | 940nm | 4W | 2-Pin/4-Pin | Multimode |
STW-WSLX-940-010-H | 940nm | 10W | 2-Pin/4-Pin | Multimode |
STW-WSLB-940-012-H | 940nm | 12W | P2 | Multimode |
STW-WSLB-940-015-H | 940nm | 15W | P2 | Multimode |
STW-WSLB-940-020-H | 940nm | 20W | P2 | Multimode |
STW-WSLB-940-030-H | 940nm | 30W | P2 | Multimode |
STW-WSLP-980-030m-M-PD | 980nm | 30mW | Coaxial | Multimode |
STW-WSLP-980-100m-M-PD | 980nm | 100mW | Coaxial | Multimode |
STW-WSLX-980-001-H-T | 980nm | 1.5W | 14-Pin | Multimode |
STW-WSLX-980-004-H | 980nm | 4W | 2-Pin/4-Pin | Multimode |
STW-WSLX-980-004-H-T | 980nm | 4W | 9-Pin | Multimode |
STW-WSLX-980-010-H | 980nm | 10W | 2-Pin/4-Pin | Multimode |
STW-WSLB-980-012-H | 980nm | 12W | P2 | Multimode |
STW-WSLB-980-015-H | 980nm | 15W | P2 | Multimode |
STW-WSLP-1055-050m-M-PD | 1055nm | 50mW | Coaxial | Multimode |
STW-WSLB-1064-015-H | 1064nm | 15W | P2 | Multimode |
STW-WSLX-1064-001-H | 1064nm | 1.5W | 2-Pin/4-Pin | Multimode |
STW-WSLX-1064-001-H-T | 1064nm | 1.5W | 14-Pin | Multimode |
STW-WSLX-1064-002-H | 1064nm | 2W | 2-Pin/4-Pin | Multimode |
STW-WSLX-1064-002-H-T | 1064nm | 2W | 9-Pin | Multimode |
STW-WSLB-1064-010-H | 1064nm | 10W | P2 | Multimode |
STW-WSLX-1064-004-H | 1064nm | 4W | 2-Pin/4-Pin | Multimode |
STW-WSLX-1064-004-H-T | 1064nm | 4W | 9-Pin | Multimode |
STW-WSLX-1310-700m-H | 1310nm | 700mW | 4-Pin | Multi-mode |
STW-WSLX-1310-700m-H-T | 1310nm | 700mW | 9-Pin | Muiti-mode |
STW-WSLB-1310-002-H | 1310nm | 2W | P2 | Multimode |
STW-WSLB-1310-005-H | 1310nm | 5W | P2 | Multimode |
STW-WSLX-1330-700m-H | 1330nm | 700mw | 4-Pin | Multimode |
STW-WSLX-1330-700m-H-T | 1330nm | 700mW | 9-Pin | Multimode |
STW-WSLB-1330-002-H | 1330nm | 2W | P2 | Muitimode |
STW-WSLB-1330-005-H | 1330nm | 5W | P2 | Multimode |
STW-WSLX-1450-350m-H | 1450nm | 350mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-1450-003-H | 1450nm | 3W | 2-Pin/4-Pin | Multimode |
STW-WSLX-1450-001-H | 1450nm | 1W | 4-Pin | Multimode |
STW-WSLX-1450-001-H-T | 1450nm | 1W | 9-Pin | Multimode |
STW-WSLB-1450-012-H | 1450nm | 12W | P2 | Multimode |
STW-WSLB-1450-015-H | 1450nm | 15W | P2 | Multimode |
STW-WSLX-1470-650m-H | 1470nm | 650mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-1470-003-H | 1470nm | 3W | 2-Pin/4-Pin | Multimode |
STW-WSLB-1470-012-H | 1470nm | 12W | P2 | Multimode |
STW-WSLB-1470-015-H | 1470nm | 15W | P2 | Multimode |
STW-WSLX-1470-700m-H | 1470nm | 700mW | 4-Pin | Multimode |
STW-WSLX-1470-700m-H-T | 1470nm | 700mW | 9-Pin | Multimode |
STW-WSLX-1530-001-H | 1530nm | 1W | 4-Pin | Multimode |
STW-WSLX-1530-001-H-T | 1530nm | 1W | 9-Pin | Multimode |
STW-WSLB-1530-010-H | 1530nm | 10W | P2 | Multimode |
STW-WSLX-1550-650m-H | 1550nm | 650mW | 2-Pin/4-Pin | Multimode |
STW-WSLX-1550-650m-H-T | 1550nm | 650mW | 9-Pin | Multimode |
STW-WSLX-1550-001-H | 1550nm | 1W | 4-Pin | Multimode |
STW-WSLX-1550-001-H-T | 1550nm | 1W | 9-Pin | Multimode |
STW-WSLB-1550-010-H | 1550nm | 10W | P2 | Multimode |
Ultra-Stable Power Output
Compact Single Box Design
Low Power Consumption
Several Wavelengths Available
Free-space or Fibered Outputs
Raman Excitation Source
Flow Cytometry
Semiconductor Processing
Real-time Process Control
Metrology
Unit | 405nm | 405nm | 488nm | 515nm | 520nm | 633nm | 637nm | 660nm | 885nm | |
Operation Specifications | ||||||||||
Free-Space Output Power | mW | 10 | 150 | 50 | 25 | 45 | 90 | 6 | 110 | 110 |
Fibered Output Power* | mW | - | - | - | 8 | 15 | 35 | 3 | 45 | 45 |
Spectral linewidth (typical) | nm | 1–2 | 1–2 | |||||||
Wavelength stability (over 8 hours) | nm | ±1 | ±1 | |||||||
Optical power stability (over 8 hours)** | % pk-pk | <0.4 | <2 | |||||||
Noise (10Hz–100MHz) | % rms | 0.2 | 0.2 | |||||||
Adjustable Output Power | % | 10-90 | 5–100 | |||||||
Free Space Optical Specifications | ||||||||||
Beam quality (m^2 typical) vertical | 1.2 | 1.2 | ||||||||
Beam quality (m^2 typical) horizontal | 1.1 | 1.1 | ||||||||
Beam size vertical | mm | 1.2 | 1.2 | 1.8 | 1.8 | 1.8 | 1.2 | 2.4 | 1.2 | 1.2 |
Beam size horizontal | mm | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.8 | 0.6 |
Beam aspect ratio | 2 | 2 | 3 | 3 | 3 | 2 | 4 | 1.5 | 2 | |
Beam divergence—vertical | mrad | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.5 | 0.8 | 0.8 |
Beam divergence—horizontal | mrad | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | |||
Beam pointing stability (over 8 hours) | μrad | <50 | <50 | |||||||
Beam pointing accuracy | degrees | 1 | 1 | |||||||
Polarization ratio | linear | 100:1 | 100:1 | |||||||
Electrical Specifications | ||||||||||
DC input (max) | 0.5A@9V | 2.1A @ 3.3V | ||||||||
DC input 2 | 2A@3.3V | - | ||||||||
Warm-up time (typical) | sec | 10 | 10 | |||||||
Power consumption (typical/max) | W | <12 | < 7 | |||||||
Interface & connector | USB & 10-pin I/O connectors | USB & 10-pin I/O connectors | ||||||||
Environmental Specifications | ||||||||||
Weight | gram | 134 | 134 | |||||||
Size | cm3 | 86 | 86 | |||||||
Case temperature | °C | 10-40 | 10-40 | |||||||
Humidity (non-condensing) | % | 5-95 | 5-95 |
Ordering Information: Part Number System: STU-PLM-XXX.X–YYY, where XXX.X is the specific wavelength, YYY is Fiber Type or Free-space.
Part Number | Fiber Type | Wavelengths Available |
STU-PLM-XXX.X-SMF | 3.5μm MFD | 514 and 520 nm |
STU-PLM-XXX.X-PMF | 3.5μm MFD PANDA | 514 and 520 nm |
STU-PLM-XXX.X-SMF | 4.3μm MFD | 633, 637 and 660 nm |
STU-PLM-XXX.X-SMF | 5.3μm MFD | 785 nm |
STU-PLM-XXX.X-PMF | 4.3μm MFD PANDA | 633, 637 and 660 nm |
STU-PLM-XXX.X-PMF | 5.3μm MFD PANDA | 785 nm |
STU-PLM-XXX.X-MMF | 50, 62.5 and 105μm MMF | All |
STU-PLM-XXX.X-FS | (Free-space) | All |
Wavelength range 405-1064 nm
High output power up to 4000W@ 915/980 nm
Are designed for fiber laser, solid state laser pumping, direct diode material processing, surgical lasers and medical therapeutics
Part Number | Wavelength (nm) | Power (W) | Fiber Type (MM fiber) |
STC-LDM-405-10 | 405 nm | 10 | 800 µm |
STC-LDM-405-35 | 405 nm | 35 | 800 µm |
STC-LDM-444-10 | 444 nm | 10 | 100, 200, 400µm |
STC-LDM-444-25 | 444 nm | 25 | 100, 200, 400µm |
STC-LDM-450-6 | 450 nm | 6 | 105 µm |
STC-LDM-450-9 | 450 nm | 9 | 200 µm |
STC-LDM-450-12 | 450 nm | 12 | 200 µm |
STC-LDM-450-50 | 450 nm | 50 | 400 µm |
STC-LDM-450-120 | 450 nm | 120 | 800 µm |
STC-LDM-520-30 | 520 nm | 30 | 400 µm |
STC-LDM-520-70 | 520 nm | 70 | 800 µm |
STC-LDM-638-15 | 638 nm | 15 | 400 µm |
STC-LDM-638-35 | 638 nm | 35 | 800 µm |
STC-LDM-793-8 | 793 nm | 8 | 105 µm |
STC-LDM-793-16 | 793 nm | 16 | 105 µm |
STC-LDM-793-30 | 793 nm | 30 | 105 µm |
STC-LDM-808-7 | 808 nm | 7 | 105 µm |
STC-LDM-808-15 | 808 nm | 15 | 400 µm |
STC-LDM-808-20 | 808 nm | 20 | 400 µm |
STC-LDM-808-30 | 808 nm | 30 | 400 µm |
STC-LDM-808-40 | 808 nm | 40 | 200 µm |
STC-LDM-808-50 | 808 nm | 50 | 400 µm |
STC-LDM-808-60 | 808 nm | 60 | 200 µm |
STC-LDM-808-100 | 808 nm | 100 | 400 µm |
STC-LDM-808-150 | 808 nm | 150 | 400 µm |
STC-LDM-878.6-25 | 878.6 nm | 25 | 200 µm |
STC-LDM-878.6-30 | 878.6 nm | 30 | 400 µm |
STC-LDM-878.6-60 | 878.6 nm | 60 | 400 µm |
STC-LDM-878.6-72 | 878.6 nm | 72 | 400 µm |
STC-LDM-878.6-75 | 878.6 nm | 75 | 400 µm |
STC-LDM-878.6-120 | 878.6 nm | 120 | 400 µm |
STC-LDM-915-10 | 915 nm | 10 | 105 µm |
STC-LDM-915-20 | 915 nm | 20 | 105 µm |
STC-LDM-915-30 | 915 nm | 30 | 105 µm |
STC-LDM-915-50 | 915 nm | 50 | 200 µm |
STC-LDM-915-80 | 915 nm | 80 | 105 µm |
STC-LDM-915-150 | 915 nm | 150 | 105 µm |
STC-LDM-915-260 | 915 nm | 260 | 200 µm |
STC-LDM-925-200 | 925 nm | 200 | 135 µm |
STC-LDM-976-10 | 976 nm | 10 | 105 µm |
STC-LDM-976-20 | 976 nm | 20 | 105 µm |
STC-LDM-976-27 | 976 nm | 27 | 105 µm |
STC-LDM-976-60 | 976 nm | 60 | 105 µm |
STC-LDM-976-100 | 976 nm | 100 | 105 µm |
STC-LDM-976-130 | 976 nm | 130 | 105 µm |
STC-LDM-976-140 | 976 nm | 140 | 105 µm |
STC-LDM-980-15 | 980 nm | 15 | 200 µm |
STC-LDM-980-35 | 980 nm | 35 | 300 µm |
STC-LDM-1064-10 | 1064 nm | 10 | 200 µm |
STC-LDM-1470-15 | 1470 nm | 15 | 200 µm |
Parameter | Symbol | Typical | Unit | |
Optical | CW Out Power | Pop | 150 | W |
Center Wavelength | | 808±10 | nm | |
Spectral Width (90% of Power) | △ | <10.0 | nm | |
Wavelength Shift with Temperature | △/△T | 0.35 | nm / ℃ | |
Electrical | Threshold Current | Ith | 1.9 | A |
Operating current | Iop | 12 | A | |
Operating Voltage | Vop | 30 | V | |
Slope Efficiency | η | 14.9 | W/A | |
Power Conversion Efficiency | ηep | 42 | % | |
Fiber | Core Diameter | dcore | 400 | μm |
Cladding Diameter | dclad | 440 | μm | |
Buffer Diameter | dbuffer | 700 | μm | |
Numerical Aperture | NA | 0.22 | - | |
Fiber Length | L | 1.0 | m | |
Connector | - | SMA905,FC | - | |
Accessories | Aiming Laser(650nm) | - | None | - |
Monitor Photodiode | - | None | - | |
Dimension | 142x72x29.5 | mm |
Optical | Unit | Typical Value |
CW Output Power | W | 15 |
Center Wavelength | nm | 980±10 |
Spectral Width (90% of Power) | nm | 4 |
Wavelength Shift with Temperature | nm / ℃ | 0.3 |
Electrical | ||
Threshold Current | A | 0.7 |
Operating Current | A | 9.0 |
Operating Voltage | V | 3.6 |
Slope Efficiency | W / A | 1.8 |
Power Conversion Efficiency | % | 46 |
Aiming Laser* | ||
CW Output Power | mW | 1 |
Center Wavelength | nm | 650±10 |
Operating Current | mA | <30 |
Operating Voltage | V | ~2.2 |
Fiber** | ||
Fiber Core Diameter | m | 200 |
Fiber Cladding Diameter | m | 220 |
Fiber Buffer Diameter | m | 500 |
Numerical Aperture | - | 0.22 |
Fiber Length | m | 1.0 |
Fiber Connector | - | SMA905 |
Dimension | mm | 52x35x17.2 |
*Optional built-in constant power circuit, 5V power supply needed. Optional constant voltage green aiming beam.
**Customized fiber and connector available.
Wavelength range 405-1550 nm
Output power range 1-5000mW
Fiber coupled Fabry Perot (FP) laser diodes
Optional FC/PC or FC/ APC connector
Distributed feedback (DFB)
Wavelength (nm) | Power (mW) | Laser Type | Package |
405 nm | 1-50 | SM / PM fiber | Coaxial |
405 nm | 5-200 | MM fiber | Coaxial |
635 nm | 1-100 | SM / PM fiber | Coaxial |
635 nm | 5-350 | MM fiber | Coaxial |
650 nm | 5-100 | SM / PM fiber | Coaxial |
785 nm | 20-50 | SM / PM fiber | Coaxial |
785 nm | 50-80 | MM fiber | Coaxial |
808 nm | 30 | SM / PM fiber | Coaxial |
808 nm | 100-150 | MM fiber | Coaxial |
880 nm | 1-2 | SM / PM fiber | Coaxial |
880 nm | 5 | MM fiber | Coaxial |
905 nm | 1-30 | SM / PM fiber | Coaxial |
940 nm | 30 | SM / PM fiber | Coaxial |
980 nm | 5-15 | SM fiber | Coaxial |
980 nm | 20-100 | MM fiber | Coaxial |
1064 nm | 5-50 | SM / PM fiber | Coaxial |
1064 nm | 20 | MM fiber | Coaxial |
1310 nm | 2-10 | SM / PM fiber | Coaxial / Pigtailed |
1310 nm | 10 | MM fiber | Coaxial / Pigtailed |
1550 nm | 2-10 | SM / PM fiber | Coaxial / Pigtailed |
1550 nm | 10 | MM fiber | Coaxial / Pigtailed |
(1) SM/PM Pigtailed Laser Diode at 650nm
with SM Fiber
with PM Fiber
Offer Customized Products
Offer OEM Coupling Service
Part Number | STC-SLDP-650-5-SM | STC-SLDP-650-10-SM | STC-SLDP-650-20-SM | STC-SLDP-650-20-SM-9 | STC-SLDP-650-30-SM |
Center Wavelength@25°C (nm) | 650nm | 650nm | 650nm | 650nm | 650nm |
Power (mW) | 5 | 10 | 20 | 20 | 30 |
Package | Coaxial | Coaxial | Coaxial | Coaxial | Coaxial |
Tolerance (nm) | 5 | 5 | 5 | 5 | 5 |
Fiber Type (80cm length) | 4µm SM fiber | 4µm SM fiber | 4µm SM fiber | 9µm SM fiber | 4µm SM fiber |
Fiber Connector | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 |
Threshold Current (Typ.) | 40mA | 45mA | 40mA | 45mA | 50mA |
Operating Current (Typ.) | 90mA | 100mA | 170mA | 150mA | 220mA |
Operating Voltage | 2.7V | 2.7V | 2.4V | 2.4V | 2.5V |
Reverse Voltage | 2.0V | 2.0V | 2.0V | 2.0V | 2.0V |
Operating Temperature | -10-+70°C | -10-+60°C | -10-+60°C | -10-+60°C | -10-+60°C |
Storage Temperature | -40-+85°C | -40-+85°C | -40-+85°C | -40-+85°C | -40-+85°C |
Lead Soldering Temperature | 260°C | 260°C | 260°C | 260°C | 260°C |
Part Number | STC-SLDP-650-50-SM | STC-SLDP-650-50-SM-9 | STC-SLDP-650-50-PM | STC-SLDP-650-100-SM | STC-SLDP-650-100-SM-9 | STC-SLDP-650-100-PM | ||
Center Wavelength@25°C (nm) | 650nm | 650nm | 650nm | 650nm | 650nm | 650nm | ||
Power (mW) | 50 | 50 | 50 | 100 | 100 | 100 | ||
Package | Coaxial | Coaxial | Coaxial | Coaxial | Coaxial | Coaxial | ||
Tolerance (nm) | 5 | 5 | 5 | 5 | 5 | 5 | ||
Fiber Type (80cm length) | 4µm SM fiber | 9µm SM fiber | PM UV fiber | 4µm SM fiber | 9µm SM fiber | PM UV fiber | ||
Fiber Connector | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | FC/SC/SMA905 | ||
Threshold Current (Typ.) | 50mA | 50mA | 55mA | 55mA | 55mA | 55mA | ||
Operating Current (Typ.) | 220mA | 200mA | 200mA | 260mA | 260mA | 260mA | ||
Operating Voltage | 2.6V | 2.5V | 2.5V | 2.7V | 2.7V | 2.7V | ||
Reverse Voltage | 2.0V | 2.0V | 2.0V | 2.0V | 2.0V | 2.0V | ||
Operating Temperature | -10-+50°C | -10-+60°C | -10-+50°C | -10-+50°C | -10-+50°C | -10-+50°C | ||
Storage Temperature | -40-+85°C | -40-+85°C | -40-+85°C | -40-+85°C | -40-+85°C | -40-+85°C | ||
Lead Soldering Temperature | 260°C | 260°C | 260°C | 260°C | 260°C | 260°C |
(2) SM/PM Pigtailed Laser Diode at 980nm
980nm Coaxial Package Diode Laser
with SM Fiber
with PM Fiber
Built-in PD
Offer Customized Products
Offer OEM Coupling Service
Part Number | STC-SLDP-980-5-SM | STC-SLDP-980-10-SM | STC-SLDP-980-10-SM-9 | STC-SLDP-980-15-SM |
Center Wavelength@25°C (nm) | 980nm | |||
Power (mW) | 5 | 10 | 10 | 15 |
Package | Coaxial | |||
Tolerance (nm) | 5 | |||
Fiber Type (80cm length) | 6µm SM fiber | 6µm SM fiber | 6µm SM fiber | 9µm SM fiber |
Fiber Connector | FC/SC/SMA905 | |||
Threshold Current (Typ.) | 10mA | 15mA | 10mA | 15mA |
Operating Current (Typ.) | 75mA | 80mA | 75mA | 80mA |
Operating Voltage | 1.5V | 1.6V | 1.5V | 1.6V |
PD | Built-in | |||
Monitor Current | 0.5mA | 0.5mA | 0.5mA | 0.5mA |
PD Reverse Voltage | 30V | 30V | 30V | 30V |
Reverse Voltage | 2.0V | 2.0V | 2.0V | 2.0V |
Operating Temperature | -10-+40°C | -10-+40°C | -10-+40°C | -10-+40°C |
Storage Temperature | -15-+85°C | -15-+85°C | -15-+85°C | -15-+85°C |
Lead Soldering Temperature (10 sec.) | 250°C |
with MM Fiber
Offer Customized Products
Offer OEM Coupling Service
Part Number | STC-MLDP-980-20-MM | STC-MLDP-980-100-MM |
Center Wavelength@25°C (nm) | 980nm | 980nm |
Spectral Width (FWHM) | 2.0nm | 2.0nm |
Power (mW) | 20 | 100 |
Package | Coaxial | Coaxial |
Tolerance (nm) | 10 | 10 |
Fiber Type (80cm length) | MM fiber | MM fiber |
Fiber Connector | FC/SC/SMA905 | FC/SC/SMA905 |
Threshold Current (Typ.) | 10mA | 55mA |
Operating Current (Typ.) | 75mA | 350mA |
Operating Voltage | 1.5V | 1.6V |
Reverse Voltage | 2.0V | 2.0V |
Operating Temperature | -10-+40°C | -10-+40°C |
Storage Temperature | -15-+85°C | -15-+85°C |
Lead Soldering Temperature | 260°C(10 sec.) | 260°C(10 sec.) |
Our STK series fiber-coupled laser diodes can be pided into two categories: single emitter laser diodes and multi-single emitter laser diodes.
Single emitter laser diodes can provide multi-wavelength covering 405nm to 976nm, output power from 2mW to 10W. Mainly used in the area of fiber laser pumping ,computer to plate(CTP), DPSS laser pumping, medical use, aiming beam, industry etc. For different application, varieties of packages with optional functions of aiming beam, photo detector, TEC, fiber detector, thermistor and other functions are available.
Multiple single emitter laser diodes build upon the foundation of multi-emitter coupling technology, to obtain high power and high brightness diode laser. Varieties of packages with optional functions of aiming beam, photo detector, TEC, fiber detector, thermistor and other functions are available. Multi single emitter laser diodes have great advantages in high reliability and high performance. In multi-single emitter laser diodes, we have patented many improved optical designs. And these compact packages and commercially recognized formats allow easy integration into the existing products. Multi single emitter diode lasers include wavelengths from 635nm-1064nm, output power from 1.6W-500W.
405nm | 445/450nm | 520nm | 635nm | 785nm | 793nm | 808nm | |
160mW | 800mW 3W 20W 50W 200W | 2mW 5mW 10mW | 2mW 20mW 400mW 1.8W 5W | 600mW | 4W 8W 12W 16W 30W 50W 80W 140W 180W | 4W 8W 10W 15W 20W 25W 30W 30W(STH) 40W 55W 60W 70W 150W | |
830nm | 878.6nm | 888nm | 915nm | 940nm | 976nm | 976nm wavelength stabilized | 1064nm |
600mW 1W 2W | 30W(STH) 65W 65W(STH) 80W(STH) 120W 120W(STH) 175W(STH) | 40W 80W 120W | 10W 12W 30W 35W 70W 100W 130W 160W 180W 300W 500W | 10W 20W 30W 70W 150W 200W 500W | 10W 15W 20W 30W 70W 150W 200W 330W 500W | 3W 9W 18W 27W 50W 60W 100W 130W 140W 180W | 10W 15W 20W |
Wavelength | Power | Fiber | Package | Type |
405nm | 160mW | 40μm/0.22 | Coaxial | |
445nm | 3W | 105μm/0.22 | ||
445nm | 20W | 105μm/0.22 | ||
445nm | 50W | 200UM/0.22 | ||
445nm | 200W | 200um/0.22 | ||
450nm | 800mW | 105μm/0.22 | 14 pin Butterfly | |
520nm | 2mW | 4μm/0.13 | Coaxial | |
520nm | 5mW | 4μm/0.13 | Coaxial | |
520nm | 10mW | 105μm/0.22 | Coaxial | |
635nm | 20mW | 4μm/0.13 | Coaxial | Single Emitter, SM |
635nm | 50mW | 105μm/0.22 | Coaxial | Single Emitter, MM |
635nm | 400mW | 105µm/0.22 | Coaxial | Single Emitter, MM |
635nm | 1.8W | 105µm/0.22 | 16 pin | Multi-single Emitter, MM |
635nm | 5W | 105µm/0.22 | 8pin module | Multi-single Emitter, MM |
650nm | 2mW | 4μm/0.13 | Coaxial | Single Emitter, SM |
650nm | 4mW | 105μm/0.22 | Coaxial | Single Emitter, MM |
660nm | 5mW-30mW | 4μm/0.13 | Coaxial | Single Emitter, MM |
660nm | 10mW-60mW | 105μm/0.22 | Coaxial | Single Emitter, MM |
785nm | 600mW | 105μm/0.22 | 14 pin butterfly | Wavelength stabilized |
793nm | 4W | 105μm/0.22 | 2 pin | |
793nm | 8W | 105μm/0.22 | 2 pin module | |
793nm | 12W | 105μm/0.22 | 2pin module | |
793nm | 16W | 105μm/0.22 | 4pin module | |
793nm | 30W | 105μm/0.22 | 6pin module | |
793nm | 40W | 200μm/0.22 | 2pin module | |
793nm | 50W | 105μm/0.22 | 6pin module | |
793nm | 80W | 200μm/0.22 | 6pin module | |
793nm | 140W | 200um/0.22 | 2pin | |
793nm | 180W | 200um/0.22 | 2pin | |
808nm | 4W | 105µm/ 0.22 | 6pin | Single Emitter |
808nm | 4W | 105µm/ 0.22 | 11pin | Single Emitter |
808nm | 4W | 400µm/0.22 | 11pin (Detachable) | Single Emitter |
808nm | 7W | 200µm/0.22 | 15pin | Single Emitter |
808nm | 7W | 200µm/0.22 | 14pin (Detachable) | Single Emitter |
808nm | 8W | 200µm/0.22 | 15pin | Single Emitter |
808nm | 8W | 200μm/400µm/0.22 | 14pin (Detachable) | Single Emitter |
808nm | 13W | 200μm/0.22 | 15pin | Multi-single Emitter |
808nm | 15W | 200μm/0.22 | 15pin | Multi-single Emitter |
808nm | 25W | 400μm/0.22 | 4pin | Multi-single Emitter |
808nm | 30W | 400μm/0.22 | 4pin | Multi-single Emitter |
808nm | 30W(STH) | 400μm/0.22 | ||
808nm | 35W | 105μm/0.22 | 6pin | Multi-single Emitter |
808nm | 40W | 400μm/0.22 | 6pin | Multi-single Emitter |
808nm | 50W | 400μm/0.22 | 6pin | Multi-single Emitter |
808nm | 60W | 400μm/0.22 | 6pin | Multi-single Emitter |
808nm | 60W | 106.5μm/0.22 | 6pin | Multi-single Emitter |
808nm | 150W | 600μm/0.22 | 2pin | Multi-single Emitter |
808nm | 6W,8W,10W,15W | 400μm/0.22 | module | Fiber-bundled module |
830nm | 600mW | 105um/0.22 | ||
830nm | 1W | 50μm/0.14 | 2pin | |
830nm | 2W | 50μm/0.14 | 2pin | |
878.6nm | 30W(STH) | 400um/0.22 | ||
878.6nm | 65W | 200um/0.22 | Wavelength-stablized | |
878.6nm | 65W(STH) | 400um/0.22 | ||
878.6nm | 80W(STH) | 400um/0.22 | ||
878.6nm | 120W(STH) | 400um/0.22 | ||
878.6nm | 175W(STR) | 400um/0.22 | ||
888nm | 80W | 400μm/0.22 | module | Fiber-bundled module |
888nm | 120W | 400μm/0.22 | module | Fiber-bundled module |
915nm | 11W | 105μm/0.22 | 2pin | Single Emitter |
915nm | 20W | 105μm/0.22 | 2pin | Multi-single Emitter |
915nm | 25W | 105μm/0.15 | 2pin | Multi-single Emitter |
915nm | 30W | 105μm/0.22 | 2pin | Multi-single Emitter |
915nm | 65W | 105μm/0.15 | 2pin | Multi-single Emitter |
915nm | 70W | 105μm/0.22 | 6pin | Multi-single Emitter |
915nm | 110W | 105μm/0.15 | 6pin | Multi-single Emitter |
915nm | 150W | 105μm/0.22 | 6pin | Multi-single Emitter |
915nm | 158W | 105μm/0.22 | 6pin | Multi-single Emitter |
915nm | 180W | 106.5um/0.22 | 2pin | Multi-single Emitter |
915nm | 200W | 200μm/0.22 | 6pin | Multi-single Emitter |
915nm | 300W | 200μm/0.22 | 2PIN | Multi-single Emitter |
915nm | 400W | 200um/0.22 | 2PIN | Multi-single Emitter |
940nm | 10W | 105μm/0.22 | 2pin | Multi-single Emitter |
940nm | 20W | 105μm/0.22 | 2pin | Multi-single Emitter |
940nm | 25W | 105μm/0.15 | 2pin | Multi-single Emitter |
940nm | 30W | 105μm/0.22 | 2pin | Multi-single Emitter |
940nm | 70W | 105μm/0.22 | 6pin | Multi-single Emitter |
940nm | 200W | 135μm/0.22 | 6pin | Multi-single Emitter |
940nm | 200W | 200μm/0.22 | module | Fiber-bundled Modules |
965nm | 11W | 105μm/0.22 | 2pin | Single emitter |
965nm | 20W | 105μm/0.22 | 2pin | Multi-single Emitter |
965nm | 25W | 105μm/0.15 | 2pin | Multi-single Emitter |
965nm | 30W | 105μm/0.22 | 2pin | Multi-single Emitter |
965nm | 70W | 105μm/0.22 | 6pin | Multi-single Emitter |
965nm | 200W | 200μm/0.22 | 6pin | Multi-single Emitter |
976nm | 4W | 105μm/0.22 | 6 pin | Single emitter |
976nm | 4W | 105μm/0.22 | 9pin | Single emitter |
976nm | 4W | 200μm/0.22 | 9 pin (Detachable) | Single emitter |
976nm | 4W | 105μm/0.22 | 11 pin | Single emitter |
976nm | 4W | 200μm/0.22 | 11pin (Detachable) | Single emitter |
976nm | 10W | 200μm/0.22 | 11 pin (detachable) | Single emitter |
976nm | 15W | 200μm/0.22 | 10pin | Multi-single emitter |
976nm | 20W | 105μm/0.22 | 2pin | Multi-single Emitter |
976nm | 25W | 105μm/0.15 | 2pin | Multi-single Emitter |
976nm | 30W | 105μm/0.22 | 2pin | Multi-single Emitter |
976nm | 60W | 105μm/0.15 | 2pin | Multi-single Emitter |
976nm | 70W | 105μm/0.22 | 6pin | Multi-single Emitter |
976nm | 200W | 200μm/0.22 | 6pin | Multi-single Emitter |
976nm | 3W | 105μm/0.22 | 2pin | Wavelength stabilized series |
976nm | 9W | 105μm/0.22 | 2pin | Wavelength stabilized series |
976nm | 18W | 105μm/0.22 | 2pin | Wavelength stabilized series |
976nm | 27W | 105μm/0.22 | 4pin | Wavelength stabilized series |
976nm | 50W | 105μm/0.15 | 6pin | Wavelength stabilized series |
976nm | 60W | 105μm/0.22 | 6pin | Wavelength stabilized series |
976nm | 80W | 105μm/0.15 | 6pin | Wavelength stabilized series |
976nm | 150W | 106.5μm/0.22 | 2pin | Wavelength stabilized series |
976nm | 180W | 200μm/0.22 | 2pin | Wavelength stabilized series |
976nm | 200W | 135um/0.22 | 2pin | Wavelength stabilized series |
976nm | 330W | 200um/0.22 | 2pin | Wavelength stabilized series |
976nm | 10W,15W | 400μm/0.22 | module | Fiber-Bundled Module |
976nm | 980/808/15W | 400μm/0.22 | 15pin | Double Wavelength series |
1064nm | 10W | 200μm/0.22 | 15pin | |
1064nm | 15W | 200μm/0.22 | 15pin | |
1064nm | 20W | 200um/0.22 | 15pin |
STK – STK series laser diodes
XXX – laser wavelength, such as 405nm, 808nm,….
Y – S with pilot beam; D without pilot beam
ZZ – package, 01 means 2PIN, 03 means co-axial, 06 means 6PIN, 14 means 14PIN, 15 means 15PIN
A – output method, F means fiber, C means insert, W means window, M means module
PPPP -- output laser power
CC - others
For example, STK808D06F-2.00W, fiber coupled laser diode with 808nm wavelength, 6PIN package, 2W output.
Features:
Multiple wavelength
Multiple function
200um fiber detachable
Applications:
Medical use
Our High Power Diode Laser Modules are manufactured by adopting specialized fiber-coupling techniques, resulting in volume products with a high efficiency, stability and superior beam quality. The products are achieved by transforming the asymmetric radiation from the laser diode chip into an output fiber with small core diameter by using special micro optics. Inspecting and burn-in procedures in every aspect come to a result to guarantee each product with the reliability, stability and long lifetime.
Our research staffs are constantly improving and innovating the processing technology in the producing process, based on the professional knowledge and experience accumulated in long-terms. We are also continuously developing new products to meet customers’ specific needs.
To provide high quality products with reasonable price is our always goal.
List of Multi-wavelength Laser Diodes
Part number | Wavelength (nm) | Laser power (W) | Fiber (core/NA/connector) |
STKA060D100F003G050ML | 808/980/450/635nm | 6W/10W/5W/0.3W | 200µm/0.22/SMA905 |
STKA250D150F006G050MH | 808/980/450/635nm | 25W/15W/5W/0.6W | 200µm/0.22/SMA905 |
STKA060D100E060F003ML | 808/980/1064/635nm | 6W/10W/6W/0.3W | 200µm/0.22/SMA905 |
STKA250D150E100F006MH | 808/980/1064/635nm | 25W/15W/10W/0.6W | 200µm/0.22/SMA905 |
OPERATING NOTES
Avoid eye and skin exposure to direct radiation during operation.
ESD precautions must be taken during storage, transportation and operation.
Short-circuit is required between pins during storage and transportation.
Please connect pins to wires by solder instead of using socket when operation current is higher than 6A. Soldering point should be close to the root of the pins. Soldering temperature should be lower than 260℃ and time shorter than 10 second.
Make sure the fiber output end is properly cleaned before operation of laser. Follow safety protocols to avoid injury when handling and cutting the fiber.
Use constant current power supply to avoid surge current during operation.
Laser diode must be used according to the specifications.
Laser diode must work with good cooling.
Operation temperature ranges from 15℃ to 35℃.
Storage temperature ranges from -20℃ to +70℃.
The STK series fiber-coupled blue lasers are manufactured by adopting specialized fiber-coupling techniques, resulting in high efficiency, stability and superior beam quality. The asymmetric radiation from the laser diode chips are coupled into an output fiber with small core diameter by using special micro optics. Their prices are reasonable and cheaper in the market.
Part Number | STK450FFBFN-0.8W | STK445F03N-3W | STK445FTRFN-20W | STK445FTRFN-50W | STK445FGRFN-200W | |
Optical Parameter | Laser power(W) | 0.8 | 3 | 20 | 50 | 200 |
Wavelength(nm) | 450 | 445 | 445 | 445 | 445 | |
Tolerance(nm) | ±10 | ±10 | ±10 | ±10 | ±10 | |
Spectral width(nm) | <6 | <6 | <6 | <6 | <8 | |
Temperature drift (nm/K) | 0.3 | 0.1 | 0.1 | 0.1 | 0.1 | |
Fiber Data | Core dia.(um) | 105 | 105 | 105 | 200 | 200 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | 0.22 | |
Fiber Length (m) | 1.0 | 1.0 | 3.5 | 3.5 | 2.0 | |
Connector | NIL | SMA905 | SMA905 | SMA905 | SMA905 | |
Thermistor | K Ohm | option | 10 | 10 | 10 | |
Electrical Parameter | Operation(A) | 1.0 | 3.0 | 2.5 | 2.8 | 2.5 |
Threshold current(A) | 0.25 | 0.3 | 0.3 | 0.3 | 0.3 | |
Operation voltage(V) | 4.8 | 5.2 | 41 | 81 | 220 | |
Others | Operation temp.(oC) | 15-35 | 15-35 | 15-35 | 15-35 | 15-35 |
Store temp.(oC) | -20-+70 | -20-+70 | -20-+70 | -20-+70 | -20-+70 | |
Dimension(mm) | 30x12.7x14.8 | 20x13.6x16 | 143x68x37 | 143x68x37 | 246x204x47 | |
Pilot | option |
Part Number | STK808S06F-2W | STK808S14F-2W | STK808D14C-2W-FS | STK808D06F-2W | |
Optical Parameter | Laser power(W) | 2 | 2 | 2 | 2 |
Wavelength(nm) | 808 | 808 | 808 | 808 | |
Tolerance(nm) | ±3, ±10 | ±3, ±10 | ±3, ±10 | ±3, ±10 | |
Spectral width(nm) | <3 | <3 | <3 | <3 | |
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 105, 200 | 105 | 200 | 105, 200 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 2.5 | 2.5 | 2.5 | 2.5 |
Threshold current(A) | 0.4 | 0.4 | 0.4 | 0.4 | |
Operation voltage(V) | 1.9 | 1.9 | 1.8 | 1.9 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >10,000 | >10,000 | |
Dimension(mm) | 26x12.7x12.5 | 30x12.7x14.8 | 44.5x31.8x18 | 26x12.7x12.5 | |
Outlook | Fig. 1 | Fig. 2 | Fig. 3 | Fig. 1 | |
TEC Parameter | Max. current(A) | 2.2 | 4 | ||
Max. voltage(V) | 8.7 | 9.8 | |||
Pilot beam | Yes | Yes |
Part Number | STK808S06F-4W | STK808D14C-4W-FS | STK808S09F-4W | STK808D06F-4W | |
Optical Parameter | Laser power(W) | 4 | 4 | 4 | 4 |
Wavelength(nm) | 808 | 808 | 808 | 808 | |
Tolerance(nm) | ±3, ±10 | ±3, ±10 | ±3, ±10 | ±3, ±10 | |
Spectral width(nm) | <3 | <3 | <3 | <3 | |
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 105, 200 | 200 | 105, 200 | 105, 200 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 5 | 5 | 5 | 5 |
Threshold current(A) | 0.8 | 0.8 | 0.8 | 0.8 | |
Operation voltage(V) | 1.9 | 2.1 | 1.9 | 1.9 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >10,000 | >10,000 | |
Dimension(mm) | 26x12.7x12.5 | 44.5x31.8x18 | 44.5x31.8x18 | 26x12.7x12.5 | |
Outlook | Fig. 1 | Fig. 2 | Fig. 4 | Fig. 1 | |
TEC Parameter | Max. current(A) | 4 | 4 | 4 | |
Max. voltage(V) | 9.8 | 9.8 | 9.8 | ||
Pilot beam | Yes | Yes |
Part Number | STK808D14C-8W-FS | STK808S09F-8W | STK808D15F-8W | STK808S02M-10W | |
Optical Parameter | Laser power(W) | 8 | 8 | 8 | 10 |
Wavelength(nm) | 808 | 808 | 808 | 808 | |
Tolerance(nm) | ±3, ±10 | ±3, ±10 | ±3, ±10 | ±10 | |
Spectral width(nm) | <3 | <3 | <3 | ||
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 200 | 200, 400 | 200, 400 | 375 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 10 | 10 | 10 | 2.6 |
Threshold current(A) | 1.5 | 1.5 | 1.5 | 0.4 | |
Operation voltage(V) | 2.2 | 2.2 | 2.18 | 10 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >10,000 | >10,000 | |
Dimension(mm) | 44.5x31.8x18 | 44.5x31.8x18 | 44.5x31.8x18 | 123x80x25 | |
Outlook | Fig. 3 | Fig. 4 | Fig. 8 | Fig. 5 | |
TEC Parameter | Max. current(A) | 6 | 6 | 6 | |
Max. voltage(V) | 9.8 | 9.8 | 9.8 | ||
Pilot beam | Yes | Yes |
Part Number | STK808S02M-15W | STK808SABC-15W | STK808SABC-30W | STK808DANC-30W-FS | |
Optical Parameter | Laser power(W) | 15 | 15 | 30 | 30 |
Wavelength(nm) | 808 | 808 | 808 | 808 | |
Tolerance(nm) | ±10 | ±3 | ±3 | ±3, ±10 | |
Spectral width(nm) | <3 | <3 | <3 | ||
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 375 | 400 | 400 | 400 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 3 | 9 | 9.5 | 10 |
Threshold current(A) | 0.4 | 1.2 | 1.2 | 1.2 | |
Operation voltage(V) | 14 | 3.8 | 7.8 | 7.8 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >10,000 | >10,000 | |
Dimension(mm) | 123x80x25 | 47x40x20 | 47x40x20 | 52x35x20 | |
Outlook | Fig. 5 | Fig. 6 | Fig. 6 | Fig. 7 | |
Pilot beam | Yes |
Specifications of Pilot Beam
Laser power(mW) | >2 |
Laser wavelength(nm) | 650 |
Operation voltage(V) | 2.2 |
Operation current(mA) | <30 |
Part Number | SYK976S06F-3W | SYK976S14F-3W | SYK976SA2F-9W-R-G | SYK976D14C-10W-FS | |
Optical Parameter | Laser power(W) | 3 | 3 | 9 | 10 |
Wavelength(nm) | 976 | 976 | 976 | 976 | |
Tolerance(nm) | ±3, ±10 | ±3, ±10 | ±0.5 | ±3, ±10 | |
Spectral width(nm) | <3 | <3 | <0.5 | <3 | |
Temperature drift (nm/K) | 0.3 | 0.3 | 0.02 | 0.3 | |
Fiber Data | Core dia.(um) | 105, 200 | 105 | 105 | 200 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 4 | 3.8 | 11.5 | 12 |
Threshold current(A) | 0.4 | 0.4 | 0.6 | 0.5 | |
Operation voltage(V) | 1.8 | 1.8 | 1.8 | 1.9 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >100,000 | >10,000 | |
Dimension(mm) | 30x12.7x14.8 | 30x12.7x14.8 | 26x12.7x12.5 | 44.5x31.8x18 | |
Outlook | Fig. 1 | Fig. 2 | Fig. 11 | Fig. 3 | |
TEC Parameter | Max. current(A) | 2.2 | 6 | ||
Max. voltage(V) | 8.7 | 9.8 | |||
Pilot beam | Yes |
Part Number | SYK976S09F-10W | SYK976D15F-10W | SYK976S02M-10W | SYK976S02M-15W | |
Optical Parameter | Laser power(W) | 10 | 10 | 10 | 15 |
Wavelength(nm) | 976 | 976 | 976 | 976 | |
Tolerance(nm) | ±3, ±10 | ±3, ±10 | ±10 | ±10 | |
Spectral width(nm) | <3 | <3 | |||
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 105, 200 | 105, 200 | 375 | 375 |
NA | 0.22 | 0.22 | 0.22 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 12 | 12 | 3.6 | 3.8 |
Threshold current(A) | 0.5 | 0.5 | 0.3 | 0.3 | |
Operation voltage(V) | 1.9 | 1.9 | 6 | 10 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >10,000 | >10,000 | >10,000 | >10,000 | |
Dimension(mm) | 44.5x31.8x18 | 44.5x31.8x18 | 123x80x25 | 123x80x25 | |
Outlook | Fig. 4 | Fig. 8 | Fig. 5 | Fig. 5 | |
TEC Parameter | Max. current(A) | 6 | 6 | ||
Max. voltage(V) | 9.8 | 9.8 | |||
Pilot beam | Yes |
Part Number | SYK976SABF-25W-R-G | SYK9XXSA3F-25W-R | STK9XXSA3F-30W-R | STK9XXDANC-30W-FS | |
Optical Parameter | Laser power(W) | 25 | 25 | 30 | 30 |
Wavelength(nm) | 976 | 915,940,976 | 915,940,976 | 915,940,976 | |
Tolerance(nm) | ±0.5 | ±3, ±10 | ±3, ±10 | ±3, ±10 | |
Spectral width(nm) | <0.5 | <5 | <5 | <3 | |
Temperature drift (nm/K) | 0.02 | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 105 | 105 | 105 | 200 |
NA | 0.22 | 0.15 | 0.15 | 0.22 | |
Connector | SMA905 | SMA905 | SMA905 | SMA905 | |
Electrical Parameter | Operation(A) | 11 | 10 | 12 | 9.5 |
Threshold current(A) | 0.6 | 0.5 | 0.5 | 0.5 | |
Operation voltage(V) | 5.4 | 5.4 | 5.4 | 7 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 10-30 | 10-30 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+80 | -20-+80 | |
Life(hours) | >100,000 | >100,000 | >100,000 | >10,000 | |
Dimension(mm) | 47x42x20 | 42x25x17 | 42x25x17 | 52x35x20 | |
Outlook | Fig. 10 | Fig. 9 | Fig. 9 | Fig. 7 | |
Pilot beam | Yes |
Part Number | STK940SG3-50W-R | STK976SG3-50W-R | STK915FN1RN-150 | |
Optical Parameter | Laser power(W) | 50 | 50 | 150 |
Wavelength(nm) | 940 | 976 | 915 | |
Tolerance(nm) | ±0.5 | ±3, ±10 | ±10 | |
Spectral width(nm) | <0.5 | <5 | <6 | |
Temperature drift (nm/K) | 0.3 | 0.3 | 0.3 | |
Fiber Data | Core dia.(um) | 105 | 105 | 106.5 |
NA | 0.22 | 0.15 | 0.22 | |
Connector | SMA905 | SMA905 | -- | |
Electrical Parameter | Operation(A) | 12 | 12 | 22.8 |
Threshold current(A) | 0.5 | 0.5 | 1.1 | |
Operation voltage(V) | 10.8 | 10.8 | 14 | |
Others | Operation temp.(oC) | 10-30 | 10-30 | 15-35 |
Store temp.(oC) | -20-+80 | -20-+80 | -20-+70 | |
Life(hours) | >100,000 | >100,000 | ||
Dimension(mm) | 60x50x25 | 60x50x25 | 80x80x24.5 | |
Outlook | Fig. 12 | Fig. 12 | click here |
Specifications of Pilot Beam
Laser power(mW) | >2 |
Laser wavelength(nm) | 650 |
Operation voltage(V) | 2.2 |
Operation current(mA) | <30 |
The diode laser offers remarkable laser beam quality with high brightness and high optical power density. The CW optical power of up to 1000 W is delivered through various fibers with small fiber core diameter from 100 µm to 600 µm. Small numerical aperture of 0.22 yields the perfect beam source for your application.
All systems are also available with power supply and/or cooling unit. We can offer you our fibre-coupled laser systems with the wavelengths of 808 nm, 915 nm, 940nm and 980 nm.
Features
fiber easily replaceable due to plug & play fibre connector
fiber-coupled output
optical power 10...1000 W
small NA of 0.22
conductively cooled package
maintenance-free
long lifetime
Applications
pumping solid state lasers
material processing
soldering
inspection
medicine
printing
plastics welding
Fiber output power [W] | Fiber core diameter (NA 0.22) | Series | ||
100μm | 200μm | 400μm | ||
30 | Y | STL-FB, STL-LM | ||
32 | Y | STL-FB, STL-LM | ||
35 | Y | STL-FB, STL-FO, STL-LM | ||
35 | Y | STL-FG | ||
40 | Y | STL-FB, STL-FO, STL-LM | ||
45 | Y | STL-FG | ||
50 | Y | STL-FG | ||
60 | Y | Y | STL-FG | |
60 | Y | STL-FP | ||
70 | Y | STL-FP | ||
80 | Y | STL-FP | ||
100 | Y | STL-AV5 | ||
120 | Y | STL-AV5 | ||
180 | Y | STL-AV5 | ||
200 | Y | STL-AV10 | ||
350 | Y | STL-AV10 |
High brightness laser for medical, pump and material processing applications
SMA905 Plug & Play connector for optical fibers
Compact dimensions
Passively cooled
2 temperature sensors (NTC/PT100)
Optical Data | ||
CW-nominal output power (W) | 30 | 32 |
Central wavelength l (nm) | 805-810, 915, 940, 975-9801 | |
Tolerance of l (nm) | ±10 (±3, ±2)2 | |
Spectral width (FWHM) (nm) | < 5 (<4)2 | |
Temperature drift of l3 (nm/K) | ~0.3, ~0.35, ~0.4 | |
Fiber data | ||
Fiber core diameter (um) | 200 | 400 |
Fiber-optic connector | SMA905 | |
Electrical data | ||
Typical operation current (start of lifetime) (A) | 40 | 40 |
Max. operation current (start of lifetime) (A) | 50 | 50 |
Max. operation current (end of lifetime) (A) | 60 | 60 |
Typical threshold current (A) | 5 - 8 | |
Typical efficiency (%) | 42 | 44 |
Typical slope efficiency (W/A) | 0.7 – 1.0 | |
Operation voltage (V) | < 2 | |
Reverse voltage (V) | < 2 | |
Thermal conditions | ||
Diode operation temperature2 (oC) | +15 … 30 | |
Storage temperature (oC) | -20 … +60 | |
Recommended heat sink capacity (W) | > 80 | |
Recommended heat sink thermal resistance (K/W) | < 0.1 | |
Other specifications | ||
Expected lifetime5 (hours) | 20,000 | |
RoHS 2002/95/EC and CE compliant | YES | |
Dimension of laser head (connector not included) (mm) | 75x25x18 (without pilot beam) 75x25x53 (with pilot beam) | |
Weight (g) | 300 |
1 Other wavelength on request; 2 optional; 3 Depending on wavelength; 4 Measured by NTC/PT100 at temperature measurement hole defined in drawing; 5 According ISO 17526:2003 (E)
Optional accessories | |
Pilot beam | |
Pilot beam output power (mW) | > 0.7 |
Pilot beam wavelength (nm) | 635 ± 5 |
Pilot beam voltage (V) | 3-5 |
Pilot beam current (mA) | < 120 |
Monitor diode | |
Operation voltage (Vdc) | 5 |
Monitor diode signal (V) | 0-2 |
STL-FB xxx | F-xxxx | - xxxx | - xxxx | - xxxx | - xxx |
Power | Fiber core diameter | Wavelength | Wavelength tolerance | Feature monitor diode | Feature pilot laser |
30 32 | 200 400 | 808, 806, 807, 808, 809, 810, 915, 940 | T0=±10nm T2=±2nm T3=±3nm | M0=no monitor diode M3=monitor diode | P0=no pilot laser P2=pilot laser |
Example: STL-FB30F200-980-T3M3P0
Fiber STF-SMA905-F, 1.5m or 3m
Diode driver with TEC-cooler
Integrated Volume Holographic Grating for wavelength stabilization
Different beam shaping optics (focusing, collimating, fibre-fibre) available
Installation service and personal introduction on request
Turn-key systems available
Customized laser modules and fibers on request
High brightness laser for, pump applications
SMA905 Plug & Play connector for optical fibres
Compact dimensions
Passively cooled
Dual temperature sensor (NTC/PT100)
Hermetically sealed laser head
External radiation filter
Optical data1 | ||||
CW – nominal output power (W) | 30 | 35 | 32 | 40 |
Centre wavelength λ (nm) | 805-810, 915, 940, 975-9812 | |||
Tolerance of λ (nm) | ± 3 (± 2)3 | |||
Spectral width (FWHM) (nm) | < 4 | |||
Temperature drift of λ4 (nm/K) | ~0.3, ~0.35, ~0.4 | |||
Fibre data | ||||
Fibre core diameter (μm) | 200 | 400 | ||
Numerical aperture | 0.22 | |||
Fibre-optic connector | SMA905 | |||
Electrical data | ||||
Typical operation current (start of lifetime) (A) | 40 | 45 | 40 | 50 |
Max. Operation current (start of lifetime) (A) | 43 | 48 | 43 | 53 |
Max. Operation current (end of lifetime) (A) | 52 | 58 | 52 | 64 |
Typical threshold current (A) | 5 - 8 | |||
Typical efficiency (%) | 42 | 43 | 44 | 44 |
Typical slope efficiency (W/A) | 0.7 - 1.0 | |||
Operation voltage (V) | < 2 | |||
Reverse voltage | 0 | |||
Thermal conditions | ||||
Diode operation temperature5 (° C) | +15….30 | |||
Storage temperature (°C) | -20….+60 | |||
Recommended heat sink capacity (W) | > 64 | > 70 | > 62 | > 76 |
Recommended heat sink thermal resistance (K/W) | < 0.1 | |||
Other specifications | ||||
Expected lifetime6 (hours) | 20,000 | |||
RoHS 2002/95/EC and CE compliant | YES | |||
Dimensions of laser head (connectors not included) (mm) | 87x25x20 | |||
Weight (g) | 300 | |||
External radiation filter | Filter 1600.014, HR@1050-1130nm >99.0% (s+p pol.) or Filter 1600.036, HR @ 1025-1080nm >99.0% (s+p pol.) Other filters on request |
Optical data @ 25°C diode heat sink temperature,
Other wavelength on request,
optional,
Depending on wavelength,
Measured by NTC/PT100 at temperature measurement hole in the diode heat sink (defined in drawing)
According ISO 17526:2003(E);
Optional | |
Monitor diode | |
Operation voltage (VDC) | 5 |
Monitor diode signal (V) | 0-2 |
STL-LM xxx | F-xxxx | -DL xxxx | - xxxx | - xxxx | - xxx |
Power | Fiber core diameter | Wavelength | Wavelength tolerance | Feature monitor diode | Feature filter |
30 32 35 40 | 200 400 | 808, 806, 807, 808, 809, 810, 915, 940, 975, 976, 977, 978, 979, 980, 981 | T2=±2nm T3=±3nm | M0=no monitor diode M3=monitor diode | F0=no filter F14=filter 1600.014 F36=filter 1600.036 |
Example: STL-LM30-F200-DL980-T3M3F0
Fibre SMA905-F, 1m, 2m or 3m
Diode driver with TE-cooler
Integrated Volume Holographic Grating for wavelength stabilization
Different beam shaping optics (focussing, collimating, fibre-fibre) available
Installation service and personal introduction on request
Turn-key systems available
Customized laser modules and fibres on request
A leading supplier and manufacturer of a wide range of photonics products such as lasers,laser parts & machines.
Office: 10 Bukit Batok Crescent #07-02 The Spire Singapore 658079
Tel: +65 63167112
Fax: +65 63167113
W/app: +6591904616
Email: sales@sintec.sg
We always use our company's email boxes for business communication and never use any free-emails such as yahoo, hotmail, gmail etc. If you receive any email without our domain, please confirm with us via phone or wechat.
